Product Guide

Ultimate II 5.5L Dry-Mist Disinfection Machine

Operation

Instructions For Use

The ideal temperature for using Ultimate II 5.5L Dry-Mist Disinfection Machine ranges from 0°C to 40°C.
If you are using the Ultimate II 5.5L Dry-Mist Disinfection Machine in a cold room, do not increase the room temperature immediately. It is recommended that you increase the room temperature to a normal gradually.
If the Ultimate II 5.5L Dry-Mist Disinfection Machine is transferred into a warm environment from a cold place where it was stored initially, wait for at least half an hour before use to prevent malfunction due to condensation on the mechanical parts.
To operate the machine, open the lid of the water tank and fill it with a 1:1 ratio of BioCair Air Purifying Solution and distilled water. Close the lid of the water tank immediately after filling.
Connect the power adaptor. Press the ‘Power Switch’ button after hearing a beep sound to switch on the machine.
To adjust the mist volume, press the ‘Mist Volume Adjustment’ button.It is recommended to set the mist volume to level 1.
To set the timer, press the ‘Timer’ button to let the timer run from 1 to 12 hours. It is recommended to set it to 1 hour of disinfection per day.
If the water level runs low, a ‘Droplet’ icon will be shown on the display.

How to Operate Ultimate II 5.5L Dry-Mist Disinfection Machine

BioCair Ultimate II - 5.5L Dry-Mist Disinfecting Machine - How to Operate Video Guide

from BioCair Singapore

Safety Feature

Ultimate II 5.5L Dry-Mist Disinfection Machine comes with a safety feature that shuts off the unit automatically when the water level runs low. An icon will be shown on the display to indicate that a refill is needed.

Product Notes

Use only with BioCair Air Purifying Solution. Using essential oils or other liquids/ substances can lead to lasting machine damage, preventing the machine from operating efficiently.
This machine can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge, if they have been given supervision or instructions concerning use of the appliance in a safe way and understand the hazards involved.
Cleaning and user maintenance shall not be made by children without adult supervision.
Children should be supervised by a parent or guardian to prevent any potential hazards.
Make sure to unplug the machine from the power source before ﬁlling or cleaning.
If the supply cord is damaged, it must be replaced by BioCair Customer Care or a qualiﬁed person in order to avoid an electrical hazard.

Caution

When in operation, do not touch the water in the groove or other parts in case of an unexpected electric shock.
Do not direct the spray nozzle at people, furniture and walls, etc. Adjust it to face an empty space instead.
Do not position the Ultimate II 5.5L Dry-Mist Disinfection Machine towards any electrical appliances, sockets and material surfaces that are sensitive to water droplets.
Do not leave it on unstable surfaces. When in operation, do not tilt or overturn it.
In case of abnormal noise or smell, please turn it off and unplug it from the power socket immediately.
Keep it away from sunlight and direct heat sources.
Do not attempt to repair or replace parts by yourself. Please send it to BioCair Customer Care for further assistance on servicing your unit. Unauthorized modifications or restructuring of the Ultimate II 5.5L Dry-Mist Disinfection Machine may lead to inconvenience or dangers.
If not in use, please unplug and store it properly.
Do not fill the water tank with abrasive or corrosive chemicals.
Do not touch or operate the Ultimate II 5.5L Dry-Mist Disinfection Machine near water or with wet hands.
Do not soak the base in water. If it is soaked in water, unplug the adaptor and contact BioCair Customer Care immediately.
Switch off the power supply before unplugging the Ultimate II Disinfection Machine.
Do not connect or disconnect the adaptor from the electrical outlet with wet hands to avoid an electrical shock.
Do not place the adaptor under the Ultimate II 5.5L Dry-Mist Disinfection Machine or any heavy items.

Storage

The original packaging is ideal to store the unit. Please store in a dust-free and moisture-free environment. Make sure the parts are cleaned properly and ensure it is completely dry before storage.

This product should not be disposed of with other household wastes throughout the EU. To prevent possible harm to the environment or human health from uncontrolled waste disposal, recycle it responsibly to promote the sustainable reuse of material resources. To return your used device, please use the return and collection systems or contact the retailer where the product was purchased.

WATER TANK

The water tank should be cleaned regularly, most preferably once every 2 weeks with clean water and a soft cloth.
Excess Air Purifying Solution left in the water tank should be used within 2 weeks.
Detach tank from machine base, empty the solution contents from the machine.
Rinse the tank with tap water, use a soft sponge to gently rub if required.
Remove mist cap from tank, rinse with tap water.

TRANSDUCER

As time passes, there might be mineral residue from the distilled water left on the object surface, transducer, water groove and ground, which affects the functionality of the machine. In order to clean the transducer, please:

Use clean water to clean the transducer.
Use a soft cloth to clean the surface of the transducer, do not use hard tools to scratch its surface.
Do not use soap or other alkaline substances to clean the transducer.

BASE

If the water groove and water level detector contain mineral sediments, clean the water groove with clean water and a soft cloth.
Soak the reservoir with 2 tablespoons of baking soda, add 4 tablespoons of vinegar. Allow it to soak for 2 hours and rinse off thoroughly with water.
For severe cases, soaking for up to 4 hrs might be required.
Do not immerse the base in water and make sure that no water went into the vents.

ISSUE	POSSIBLE REASON(S)	SOLUTION(S)
No breeze, no mist	No power supply. Power switch is off. Water level of the groove is too high. Leakage of water tank. Humidity setting is too low.	Connect to power supply. Turn on the power switch. Lower the water level by reducing water in the groove. Tighten the water lid.
Breeze, but no mist	No water in the water tank. Water level detector is not in the right position. The temperature of the unit is too low	Fill water into the water tank. Re-mount the water level detector. Place unit in a room for half an hour before use.
Odd mist smell	Water in the tank is kept for too long.	Clean the water tank and refill it with clean water.
Low mist intensity	Too much water in the water groove. Mist intensity is low. Mineral sediments on the transducer. The water is too cold. The water is unclean.	Empty the water in the groove and place the water tank again. Adjust the mist intensity. Clean the transducer. Use water of room temperature. Clean the water tank and refill it with clean water
Low spurting of mist	Mist intensity is low. Water tank and the base are not secured. Fan does not work properly	Adjust the mist intensity. Ensure water tank and the base are secured. Enlist professional help to check the fan inside the base.
Noise	Resonance caused by too little water in the water tank. Resonance caused by unstable surfaces.	Add more water into the water tank. Place unit on stable surfaces.
Water is not flowing to the base of the machine/low water blinking sign		First make sure the machine is fully off, including power supply. Detach the tank from the base. Reinsert the tank by positioning it in an upright manner. Restart the machine and wait for a few extra seconds for the water to flow down.
Water is leaking from between the tank and the base		First make sure the machine is fully off, including power supply. Detach the tank from the base. Empty the base. Reinsert the tank by positioning it in an upright manner. Restart the machine and wait for a few extra seconds for the water to flow down.
No mist is coming out E3 error		Reset the humidity button to “00” and let it automate on its own. Unscrew one of the screws circled in red, remove the float switch base pointed by the blue arrow, flip the white float switch washer.
Shaky or vibration sound		Make sure the machine is fully off, including power supply. Move the machine to the floor and make sure it is fully on a flat surface with nothing under it. Make sure it is not resting on a wire. Minimum sound is normal, as long as it does not cause too much annoyance affecting day to day activity.

ISSUE	POSSIBLE REASON(S)
No breeze, no mist	No power supply. Power switch is off. Water level of the groove is too high. Leakage of water tank. Humidity setting is too low.
Breeze, but no mist	No water in the water tank. Water level detector is not in the right position. The temperature of the unit is too low
Odd mist smell	Water in the tank is kept for too long.
Low mist intensity	Too much water in the water groove. Mist intensity is low. Mineral sediments on the transducer. The water is too cold. The water is unclean.
Low spurting of mist	Mist intensity is low. Water tank and the base are not secured. Fan does not work properly
Noise	Resonance caused by too little water in the water tank. Resonance caused by unstable surfaces.

ISSUE	SOLUTION(S)
No breeze, no mist	Connect to power supply. Turn on the power switch. Lower the water level by reducing water in the groove. Tighten the water lid.
Breeze, but no mist	Fill water into the water tank. Re-mount the water level detector. Place unit in a room for half an hour before use.
Odd mist smell	Clean the water tank and refill it with clean water.
Low mist intensity	Empty the water in the groove and place the water tank again. Adjust the mist intensity. Clean the transducer. Use water of room temperature. Clean the water tank and refill it with clean water
Low spurting of mist	Adjust the mist intensity. Ensure water tank and the base are secured. Enlist professional help to check the fan inside the base.
Noise	Add more water into the water tank. Place unit on stable surfaces.
Water is not flowing to the base of the machine/low water blinking sign	First make sure the machine is fully off, including power supply. Detach the tank from the base. Reinsert the tank by positioning it in an upright manner. Restart the machine and wait for a few extra seconds for the water to flow down.
Water is leaking from between the tank and the base	First make sure the machine is fully off, including power supply. Detach the tank from the base. Empty the base. Reinsert the tank by positioning it in an upright manner. Restart the machine and wait for a few extra seconds for the water to flow down.
No mist is coming out E3 error	Reset the humidity button to “00” and let it automate on its own. Unscrew one of the screws circled in red, remove the float switch base pointed by the blue arrow, flip the white float switch washer.
Shaky or vibration sound	Make sure the machine is fully off, including power supply. Move the machine to the floor and make sure it is fully on a flat surface with nothing under it. Make sure it is not resting on a wire. Minimum sound is normal, as long as it does not cause too much annoyance affecting day to day activity.
